Logo Sting Shape Assembly

About this style

A logo sting is a few seconds of motion that ends on a brand's lockup, usually placed at the start or end of a video. Shape-assembly stings build the mark from simple geometry and organize all the motion around a single impact frame, followed by stillness. Brands use them because a short, repeatable sting makes an identity memorable across every piece of content.

Make a 6-second logo sting plus a 4-second hold: primitives fly in, interlock on one decisive hit, and resolve into a mark and wordmark.

<inputs>
If I don't give you something, use the default and don't ask. If I supply a logo, rebuild it from SVG primitives and assemble that instead.
- Brand: meridian
- Colors: bone #F1EEE7, ink #141414, signal #FF4A1C
- Length: 6 s of motion plus a 4 s hold
</inputs>

<direction>
- The mark (240px) has four primitives: a radius-120 circle split vertically into half-discs, left in ink, right in signal and 24px lower; a 28px ink bar through the seam, extending 40px above and below; a 44px ink square capping the bar. A 16px signal dot lands later.
- Wordmark: Sora 600, lowercase, 120px, −0.02em, ink, right of the mark with a gap of 0.6× its width, x-height centered on the circle.
- Flat bone background; the final lockup is centered as a whole.
- The hit is everything. Pieces accelerate INTO contact on cubic-bezier(0.55, 0, 0.9, 0.4), arriving at full speed, all touching on one frame at 2.4 s. A stiff spring (stiffness 520, damping 22) recoils the mark from scale 1.07 to 1. At the hit, one signal ring expands from 260 to 1100px, fading over 0.45 s, and the frame jolts 8px for three frames, decaying.
- Paths are arcs, never straight. Pieces rotate in flight, land on exact angles (0°, 90°, 180°), get 100 ms of anticipation before launch, and stretch up to 12% along their velocity in place of motion blur.
- After the hit everything decelerates; the wordmark reveal uses cubic-bezier(0.16, 1, 0.3, 1).
- Premium is one strong beat, stillness around it, and pixel-aligned geometry.
Banned: particle bursts, lens flares, glow, 3D extrusion, more than ink plus one color, easing out into the hit, slow fades on the mark, shapes resembling well-known logos, emoji.
</direction>

<structure>
- 0.0–0.4: A tiny ink point appears at center and pulses once.
- 0.4–1.6: Four pieces launch from beyond the edges on arcs, 90 ms apart, rotating.
- 1.6–2.4: They swing into alignment and accelerate inward.
- 2.4: Hit: pieces lock, the ring fires, the frame jolts.
- 2.4–3.2: The recoil settles.
- 3.2–4.4: The mark slides left as the wordmark unmasks from behind it, letters 30 ms apart, tracking 0.04em → −0.02em.
- 4.4–5.0: The dot drops onto the square with a small secondary bounce.
- 5.0–6.0: Dead stop.
- 6.0–10.0: Hold, perfectly still.
For other lengths, keep the hit near 40% of the motion and the hold at least 2 s.
</structure>

<build>
- One self-contained index.html (inline CSS and JS) with a fixed 1920×1080 (16:9) stage scaled to fit the window; design for 60fps.
- window.seek(t), t in seconds, sets every visual from t alone: no CSS transitions or animations, no setTimeout/setInterval, no state carried between frames. Randomness comes from a seeded PRNG; springs are closed-form functions of time.
- Without ?render in the URL, drive seek from requestAnimationFrame so it plays in a browser; with ?render, don't start that loop.
- Google Fonts via <link> are fine. Draw everything as inline SVG whose attributes seek sets directly; no canvas or three.js needed.
</build>

<check>
Before showing me, screenshot seek(0) through seek(10), one frame per second, and look at each. Fix overlaps, clipped or cramped text, and anything generic. Also step 2.2–2.6 s at 1/60 s: every piece touches on one frame, with no gaps or overlaps once seated. Frames 6–10 s must be identical. Confirm the final frame holds.
</check>

Ours, and free to use under CC0: copy it, change it, ship it. No credit needed.
